D.5.1 Cable protection
The current-carrying capacity of conductors is determined in table 5 of EN60204-1. For your op-
eration you must determine the accordant value in the standard yourself, by taking into consid-
eration, amongst other things the cable mounting. Here you will find an extraction for the laying
of PVC- isolated cables on open cable racks:
Use suitable fuses with the enable characteristic gL or gR.
D.5.2 Cable protection + device protection
Consider by your choice of the whole range fuses the current-carrying capacity connected
mains cables and the allowable maximum load of the device.
Recommended UL-listed fuses, see ZB.4 Fuses for device-protection– on page 132.
D.6 Type of protection
D.7 Fire fighting appliances
Cable cross sec-
tion
Fuse
rated current
1.5 mm
2
16.1 A
2.5 mm
2
22 A
4 mm
2
30 A
Type of protection IP 20
Fight fire with ABC powder
