6.8 Operating sequence of installation
The following steps must be carried out at installation:
1 Lay all cables EMC-compatible.
2 Connect cables (see ZConnection diagrams– from page 48)
m Connect the motor via the terminals U/T1, V/T2, W/T3, PE. Attend to the in-phase
connection (rotational direction).
m Connect the fuses.
(in case you consider UL 508 C: use the semiconductor- or total-range-fuses, which
are UL-listed in chapter
ZD.5 Fuse protection– from page 146.)
m Connect the mains filter (if necessary).
m Connect the reactors (if necessary)
m Connect the device via the mains input terminals R/L1, S/L2 and T/L3.
m Connect the protective conductor to the terminal PE (a permanent PE connection is
required imperatively).
m Perhaps connect (dependent on the application) a braking resistor (R
B
) or a chopper
unit.
WARNING
The following may occur, if you disregard these safety notes:
m serious personal injury m death
The danger is: electricity. Parts, which are under tension are perilous.
Assure, that during the entire mounting the device, the parts, which must be mounted (e. g.
supply cables) and the mounting range are off-circuit.
All the units must be grounded directly to a common ground terminal to prevent electric shock,
fire and interference.
NOTE
Users must connect wires according to the circuit diagrams on the following pages.
Always use shielded cables.
Do not plug a modem or telephone line to the RS-485 communication port or permanent dam-
age may result. Terminals 1 and 2 are the power supply for the optional copy keypad only and
should not be used for RS-485 communication.
