Installation space
Manual b maXX
®
BM1000
Document No. 5.07003.04 Baumüller Nürnberg GmbH
36
of 174
5.4
5.4 Installation space
The following drawings show the main dimensions of the devices in mm. Use these draw-
ings, in order to determine the required space in the control cabinet. For the construction
of the necessary drilling/cut-outs use the drawings in
ZDimensions– from page 39.
5.4.1 Installation space frame 1
Option 1 (-10 to +50°C)
Option 2 (-10 to +40°C)
Figure 14: Installation space frame 1
Air flow
Air flow
