B.3
B.3 Chokes
B.3.1 Mains chokes recommended values
230V, 50/60Hz, 1-phase
460V, 50/60Hz, 3-phase
Device kW Fundamental
A
Max. continuous
A
Inductance (mH)
3~5 % impedance
BM1211 0.2 4 6 6.5
BM1212 0.4 5 7.5 3
BM1213 0.75 8 12 1.5
BM1224 1.5 12 18 1.25
BM1225 2.2 18 27 0.8
Device kW Fundamental
A
Max. continuous
A
Inductance (mH)
3% impedance 5% impedance
BM1412 0.4 2 3 20 32
BM1413 0.75 4 6 9 12
BM1414 1.5 4 6 6.5 9
BM1425 2.2 8 12 5 7.5
BM1426 3.7 8 12 3 5
BM1437 5.5 12 18 2.5 4.2
BM1438 7.5 18 27 1.5 2.5
BM1439 11 25 37.5 1.2 2
