m Operation terminal (option keypad):
Depth: 28,8 mm
Figure 19: Dimension operation terminal
5.6 Mounting instructions
Complete the mounting in the following way:
1 provide suitable mounting accessories
2 mount the device.
CAUTION
The following may occur, if you disregard these safety notes:
m minor to medium personal injury.
The danger is: sharp edges. In case, while installing, you lift a device with unprotected hands,
fingers/palm can be cut. If the device falls off, the feet can be cut.
Wear safety gloves
Wear safety shoes
