Marking of the device - type key
Manual b maXX
®
BM1000
Document No. 5.07003.04 Baumüller Nürnberg GmbH
28
of 174
4.4
m Drive frames
n Frame 1 (0,2 -1,5 kW)
Figure 5: b maXX
®
BM1000 Frame 1
n Frame 2 (0,75 - 3,7 kW)
Figure 6: b maXX
®
BM1000 Frame 2
Input Terminals
(R/L1, S/L2, T/L3)
Housing
Keypad
Control board case
Control board cover
Output terminals
(U/T1, V/T2, W/T3)
Input Terminals
(R/L1, S/L2, T/L3)
Housing
Keypad
Control board case
Control board cover
Output terminals
(U/T1, V/T2, W/T3)
