Interconnect the devices
Manual b maXX
®
BM1000
Document No. 5.07003.04 Baumüller Nürnberg GmbH
26
of 174
4.2
This data is available in the type key (see ZMarking of the device - type key– on page 27).
Figure 1: b maXX
®
BM1000
4.2 Interconnect the devices
The device is part of the Baumüller series b maXX
®
BM1000 and can be connected to-
gether with other Baumüller devices.
4.3 Overview of dangerous areas
The following overview shows the existing danger areas on the particular device. Use this
survey for an overview of the existing danger areas, if you incorporate into the handling
of this device. The explanation of the symbols, which are used you will find in
ZHazard
information and commands– from page 12.
Figure 2: Danger areas b maXX
®
BM1000
