Manual b maXX
®
BM1000
Document No. 5.07003.04
4DESCRIPTION OF THE DEVICES
In this chapter the basic construction of the device b maXX
®
BM1000 is described and
the type key on the devices is explained.
4.1 Structure
The devices of the b maXX
®
-series are converters of Baumüller Nürnberg GmbH. The
devices consist of a power unit with an integrated controller.
The rated current of the devices reach for 1-phase devices from 1.6 A to 11 A and for 3-
phase devices from 1.5 A to 24 A. The devices differ in size, power and cooling.
NOTE
The devices of the b maXX
®
BM1000-series are provided for the operation in the ’second en-
vironment’ (industrial environment) according to EN 61800-3. At connection to the public
mains EMC problems can appear. Also see
ZAppropriate use– from page 17.
NOTE
The b maXX
®
BM1000 is to be used to control 3-phase asynchronous standard motors in the
power range of 0.2 to 11
kW (rated power of the drive).
