Baumuller b maXX BM1000 - Remove Front Cover; Remove Main Terminal Cover; Remove Motor Terminal Cover; Remove Mains Terminal Cover

Preparation for installation and wiring
Manual b maXX
®
BM1000
Document No. 5.07003.04 Baumüller Nürnberg GmbH
30
of 174
4.5
4.5.2 Remove front cover
Figure 9: Remove front cover
4.5.3 Remove main terminal cover
Frame 2 and frame 3
Figure 10: Remove mains terminal cover
4.5.4 Remove motor terminal cover
Frame 2 and frame 3
Figure 11: Remove motor terminal cover
Step 1 Step 2
