Manual b maXX
®
BM1000
Document No. 5.07003.04
6INSTALLATION
In this chapter we describe the electric installation of the device. The mechanical instal-
lation is described in ZMounting– from page 33.
Before installing assure, that the technical preconditions are fulfilled:
1 Check the requirements to the electrical mains and check if the existing mains is suit-
able.
2 Check the requirements to the electrical cables and provide the according cables.
3 Check the characteristics of the connections and configure the connections according-
ly.
6.1 General safety instructions
h Pay attention to the information in the chapters ZFundamental safety instructions–
from page 11.
h Pay attention to all areas at the device, which could be dangerous for you during the
electrical installation.
Figure 21: Danger areas at the electrical installation
