B.1.3 Dimensions and weights for braking resistors
- in progress -
for further information please contact your nearest Baumüller representative.
(all dimensions are in millimeter)
R150-200-20 (150 Ω / 200 W)
R250-200-20 (250 Ω / 200 W)
Figure 69: Braking resistor 1
Model no. L1 L2 L3 W H
R400-300-20 165 150 110 30 60
