D.3 Electrical data
Voltage 230 V series
BM 1211 1212 1213 1224 1225
Max. applicable motor output
(kW)
0.2 0.4 0.75 1.5 2.2
Output rating
Rated output capacity (kVA) 0.6 1.0 1.6 2.9 4.2
Rated output current (A) 1.6 2.5 4.2 7.5 11.0
Maximum output voltage (V) 3-phase proportional to input voltage
Output frequency (Hz) 0.1 to 600 Hz
Carrier frequency (kHz) 1 to 15
Input rating
Rated input current (A) single
4.9 6.5 9.5 15.7 24
Rated voltage/frequency single
200 to 240 V, 50/60 Hz
Voltage tolerance ±10 % (180 to 264 V)
Frequency tolerance ±5 % (47 to 63 Hz)
Cooling method natural cooling fan cooling
Voltage 460 V series
BM 1412 1413 1414 1425 1426 1437 1438 1439
Max. applicable motor output
(kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Output rating
Rated output capacity (kVA) 1.2 2.0 3.3 4.4 6.8 9.9 13.7 18.3
Rated output current (A) 1.5 2.5 4.2 5.5 8.2 13 18 24
Maximum output voltage (V) 3-phase proportional to input voltage
Output frequency (Hz) 0.1 to 600 Hz
Carrier frequency (kHz) 1 to 15
Input rating
Rated input current (A) 3-phase
1.9 3.2 4.3 7.1 11.2 14 19 26
Rated voltage/frequency 3-phase, 380 to 480 V, 50/60 Hz
Voltage tolerance ±10 % (342 to 528 V)
Frequency tolerance ±5 % (47 to 63 Hz)
Cooling method natural
cooling
fan cooling
