PRODUCT DATA JANUARY 2003
HANGER BEARING & THOMAS COUPLING INSTALLATION
THOMAS COUPLING INSTALLATION
1. Hanger Support
2. Safety strap retainer
3. Hanger adapter
4. Driveshaft segments (2,3,&4)
5. Radius washer
6. Disc assembly
7. Hanger adapter
8. Radius washer
HANGER BEARING ASSEMBLY
1. Forward adapter
2. Bearing
3. Hanger
4. Spring
5. Spacer
6. Nut
7. Nut
8. Locknut
9. Aft adapter
•EXAMPLE ILLUSTRATION•
•EXAMPLE PHOTO•
