PRODUCT DATA JANUARY 2003
(lb) (Kg)
Single AFCS, SCAS 104.5 47.4
CoPilot Instruments Gold Crown 19.7 8.9
Standby Attitude Indicator 8.8 4.0
Dual Controls 20.2 9.2
CoPilot ICS 2.0 0.9
Gold Crown Harness (ElectroMech) 26.6 12.1
KTR-908 VHF Comm #2 6.0 2.7
KNR-634A NAV #1 (ElectroMech) 10.8 4.9
KNR-634A NAV #2 (ElectroMech) 6.8 3.1
KDF-806 ADF (Wheel) 8.2 3.7
KDM-706 DME (ElectroMech) 7.2 3.3
Transponder Mode S* 12.4 5.6
Gyro (ElectroMech) 12.1 5.5
Installed Weight (Wheel Gear)** 245.3 111.3
KDF-806 ADF (Wheel) Remove -8.2 -3.7
ADF KDF 806 (Skid) Add 9.5 4.3
Installed Weight (Skid Gear)** 246.6 111.9
Notes:
*Customer responsible for obtaining aircraft ID code for Mode S.
**Total installed weight approximate, depending on other
installed equipment and ballast.
DUAL PILOT IFR
AFCS SCAS/ATT
with E/M Instruments, No Flight Director
