PRODUCT DATA JANUARY 2003
430 SEATING
PILOT AND FORWARD PASSENGER SEATING
Two individual ergonomically designed energy-attenuating bucket seats with adjustable
lumbar support, each equipped with seat belt, double strap [four point] shoulder harness
and inertia reel, with "Quick Release" mechanism, are located in the cockpit. The color
and upholstery material for the seats, and interior trim of the cockpit match that which
is selected for the cabin.
Each crew and passenger seat is equipped
with a restraint assembly that consists of
an inertia reel, a shoulder harness [pilot &
left front seat have double straps / the
passenger cabin has single straps], and
an adjustable seat belt. The inertia reel is
provided with an anti-rebound lock feature
and is capable of retracting 56 centimeters
(22 inches) of web belt.
OCCUPANT RESTRAINT
CREW SEAT
FOUR POINT
RESTRAINT
HARNESS
INERTIA
REEL
