PRODUCT DATA JANUARY 2003
LITTER DOOR
No. 430-705-020-XXX
The standard left and right cabin doors open to an unobstructed area of 3 feet, 92 centimeters,
wide by 4 feet, 122 centimeters, high. The optional hinged panel [Litter] door kit consists of an
additional panel door on the left hand forward side of the cabin. The standard main door is
attached with a hinge to the panel door in a manner similar to the Bell LongRanger series. This
panel door also is hinged, and both doors can swing open to give a 54 inch, 137 centimeter,
access to the cabin to facilitate litter or bulky cargo loading. The Weight increase with the L/H litter
door kit installed is 6.4 kilograms (14.1 pounds).
LITTER DOOR
54 INCHES [1.37 METERS]
WIDE ACCESS
