BELL HELICOPTER BELL 430 - INTERNAL VOLUMES

251
THIS IS AN UNCONTROLLED DOCUMENT.
THIS ELECTRONIC DOCUMENT MAY HAVE BEEN SUPERCEDED.
THE MOST CURRENT DOCUMENT INFORMATION IS AVAILABLE
FROM YOUR BELL HELICOPTER TEXTRON REPRESENTATIVE.
PRODUCT DATA JANUARY 2003
INTERNAL VOLUMES
CABIN-SEAT TO ROOF
CREW COMPARTMENT
NOSE
CABIN-SEAT TO FLOOR
PARCEL SHELF
[CABIN FLOOR LOAD LIMIT]
[CABIN LOAD LIMIT (STRUCTURAL)]
BAGGAGE COMPARTMENT
[COMPARTMENT LOAD LIMIT]
[COMPARTMENT FLOOR LOAD LIMIT]
AFT AVIONICS COMPARTMENT
1.05M
3
(37.2FT
3
)
226.80KG(500.0LB)
488.2KG/M
2
(100LB/FT
2
)
0.10M
3
(3.7FT
3
)
0.17M
3
(6.0FT
3
)
0.6 M
3
(19 FT
3
)
488.20KG/M
2
(100LB/FT
2
)
3.9 M
3
(139 FT
3
)
1252 KG(2760LB)
1.87M
3
(65.9FT
3
)
O.40M
3
(14.2FT
3
)
