PRODUCT DATA JANUARY 2003
AIRCRAFT DATA PLATE
The manufacturers data plate is located
on the right side of the helicopter, near the
fuel filler cap.
Within the baggage compartment, there are
12 Footman loops (tie downs) located
around the perimeter of the load bearing
panel. They are stressed for an
ultimate
load limit of 499 kilograms (1100 pounds)
in any direction. The baggage compartment
structural maximum load is 227 kilograms
(500 pounds), with a deck loading limit of
448.2 KG/M
2
(100 LBS/FT
2
).
EXAMPLE
BAGGAGE STORAGE
OPTIONAL BAGGAGE COMPARTMENT
CARGO RESTRAINT NET
