PRODUCT DATA JANUARY 2003
The passenger cabin is longer than that of the Bell 222/230 to give each of the three
main cabin seat rows more pitch, making the accommodations more comfortable and
the ride more pleasant. An optional
hinged panel door kit is available to provide greater
ease of access for cargo or litters. Located between the left crew and passenger doors
it is attached by hinges to the fuselage and the passenger door in a manner similar to
the Litter Door of the Bell LongRanger & 407 series.
CABIN STRETCH WITH OPTIONAL LITTER DOOR
OPTIONAL LITTER DOOR
BAGGAGE DOOR
MAIN PASSENGER DOOR
COMFORT FEATURES
The spacious cabin is easily entered
through the wide (nearly 180°) opening
passenger doors, and provides comfortable
seating for seven (standard seats), with
ample room for baggage. The 1.05 cubic
meter (37.2 cubic feet) aft baggage
compartment is accessible through it's own
door, or through the rear cabin partition.
Cabin furnishings include the high backed
non-folding seats with three-point lap /
shoulder restraints, and the standard
deluxe interior trim, headliner /
soundproofing, hard thermoplastic wall
covering, and vinyl floor covering. The SIX
large cabin windows afford each
passenger a panoramic view. The cabin
ventilation system directs fresh outside
air to each seat from individual overhead
outlets. In flight, the cabin's occupants
receive a smooth vibration-free ride,
courtesy of the LIVE
®
suspension.
STRETCHED FUSELAGE WITH OPTIONAL PANEL DOOR
