PRODUCT DATA JANUARY 2003
Excellent visibility is provided in the crew
compartment by two large glass
windshields and acrylic windows in the
doors, lower nose, and roof. Each crew
door window has a clear vision window
in it's upper center section. The small
window is hinged at the bottom, latched at
it's top, and is sealed for protection against
wind and water.
A windshield wiper is installed on each windshield. The wipers operate in
synchronization and are controlled by a single switch located on the overhead console.
The switch has four positions, HIGH, LOW, OFF, AND PARK.
WINDSHIELD WIPERS
STANDARD GLASS WINDSHIELDS
SKYLIGHT
CLEAR VISION WINDOW
CHIN WINDOW
STANDARD WINDSHIELD WIPERS
GLASS WINDSHIELDS
