SYSTEM AREA WARNING/CAUTION/ADVISORY INDICATIONS
Additional warning, caution, and advisory messages are embedded within the SYSTEM
AREA of the IIDS displays. In most cases the message will be located in or near the
label of the effected system. The system area embedded messages are primarily related
to the Chip Detection System and the FADEC (faults, failures, overspeed, and OEI
conditions), but also include some messages duplicating or supplementing the messages
in the warning caution window.
ADDITIONAL W/C MESSAGE ARROWWARNING/CAUTION WINDOW
SYSTEM AREA W/C MESSAGES [TYPICAL]
WARNING / CAUTION / ADVISORY INDICATIONS
[ DISPLAYS IN THE IIDS SYSTEMS AREA ]
RED AMBER WHITE
ECU A/RLT 30SEC OEI OPEN (aux fuel)
PRES (fuel) BUS INT SRT ABT TRANSIT
FAIL (volt/amps) CHIP SUMP VALVE ALT
O/TRQ CHIP SCAV CHIP BRG ECU
XMSN OIL C/FL SUMP CHIP L/R QUILL dash line(fuel int)
C/FL SCAV CHIP TAIL RTR 1 M/ECU 2
FAIL CHIP COLL GEAR 1 M/OEI 2
GEN CHIP PLTRY GEAR
HYD OIL CHIP SUMP PUMP
FLTR C/FL BRG
LOW QTY C/FL L/R QUILL
FAIL (IIDS) C/FL TAIL RTR
INV C/FL COLL GEAR
2 MIN OEI C/FL PLTRY GEAR
OVSPD C/FL SUMP PUMP
ENG FIREENG FIRE
ENG FIRE
ENG FIRE
AUTOTRIM
INV 2
1 GEN
PRK BRK
DR LOCK
INSTR FAN
EXT PWR
I00 0 I00
120 0
80
99 0
52
54
56
52
0
740 50
790
4287
98
2 MIN OEI
803
LC
61
15 15
1 M/OEI
C/FL SCAVCHP R QUILL
FLTR
CHIP SUMP
LOW
PRES
VALVE
FLTR
