PRODUCT DATA JANUARY 2003
UPPER CABLE CONTROL
OPENS PLENUM DOOR
VENT OUTLET -ROTATE CLOCKWISE TO
CLOSE -COUNTER CLOCKWISE TO OPEN
LOWER CABLE CONTROL
DIVERTS AIRFLOW TO DEFOG
DEFOG NOZZLES
[ PROVISION FOR OPTIONAL
ECU / BLEED AIR HEAT]
