RECALL loads and displays all DSP parameters that are stored in the selected preset.
CAUTION: The loaded preset becomes instantly audible when in on-line mode. Be sure to
select the desired preset with the correct set of parameters. In the worst case, this could
lead to severe damage to the connected loudspeaker cabinets due to improper signal
processing!
PREVIEW reads and displays all DSP parameters that are stored in the selected preset.
This function is used to display and check a preset’s contents, without actually loading the
preset. You can neither listen to the preset nor edit its contents, as long as you do not
explicitly load it using the RECALL function.
Import / Export of Preset Files
IRIS-Net allows the storing of all DSP parameters of an amplifier together with the according preset name in a file, and
to load amplifier parameters from these files. Therefore, IRIS-Net creates a sub-directory \Presets during installation,
where all factory-presets are saved in to. It is recommended to save your own presets in this directory as well. For
improved organization, creating more sub-directories within the directory /Presets is permissible.
Element
Description
After clicking onto IMPORT PRESET appears an Open File dialog box. Enter the correct path of the
directory in which the desired file is located and select the desired preset file to be opened. This loads
and afterwards displays all DSP parameters that are stored within that file.
CAUTION: The loaded preset becomes instantly audible when in online mode. Be sure to select the
desired preset with the correct set of parameters. In the worst case, this could lead to severe
damage to the connected loud speaker cabinets due to improper signal processing!
After clicking onto EXPORT PRESET a Save File dialog box appears. Enter the correct path of the
directory that you want to save the data in. Enter a file name (without extension). Click onto the SAVE
button to store all DSP parameters together with the corresponding file name. “.ds” is automatically
added as file extension.
Import of EV RACE Files
Element
Description
IRIS-Net allows importing loudspeaker presets that have been created in Electro-Voice RACE by
clicking onto the button IMPORT RACE FILE to open the following dialog box.
IRIS-Net
REMOTE AMPLIFIER | en 123
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
