/IDX3E pilotgenerator
level
-128...+40 dB(u) at power amp output
/IDX3F config type 0...7 0 = fullrange, 1 = sub, 2 = sublo, 3 = lo, 4 = lomid, 5 = mid, 6 = midhi, 7 = hi
/IDX40 config description can't be represented by numerical value
/IDX41 speaker
protection
can't be represented by numerical value
/IDX42 thermo limiter can't be represented by numerical value
STATE/ERROR FLAGS
The available state/error flags are divided into following groups:
– Global power amplifier / remote control module (Device State Flags),
– Amplifier's input channels (Input Channel State Flags)
– Amplifier's output channels (Output Channel State Flags)
Device State Flags
Flag
Description
POWER The amplifier is in powered state (after power up delay gone) (collect / GPO reads inverted)
STANDBY The amplifier is in standby state
CANPOLL There is a timeout at master PCs CAN polling
NONVLT There is a error in non volatile memory handling
COLLECT Locally collected error state detection via individual mask for device and all input/output channels (can
be cleared by command)
GLOBAL Globally collected error state of all selected other amps
OVT Amplifier temperature is above upper limit
DIRTY Current preset parameter setting is edited
PRSGATE The possibility of a "dangerous" preset change is enabled
BRIDGED The amplifier's bridged mode is selected.
PARALLEL The amplifier's parallel routing is selected
GNDLIFT The connection switch "chassis to ground" is open
LEVELCTRL The level controls at the power amp's front panel are disabled
VOLTDOUB The mains voltage-doubler is active, 115V-mode
THERMSD The thermal shutdown is active
CBPWARN The circuit-breaker-protection is close before action
AESLOCK The AES/EBU digital audio interface is in locked state (collect / GPO reads inverted)
ERRDISP The LC-display indicates a error message
AESERROR The AES/EBU digital audio interface is in erratic state
VLT_WARN Mains voltage warning
IRIS-Net REMOTE AMPLIFIER | en 231
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
