EXTENSION The number of call station extensions is to high or the addresses of the extensions
are not correct.
MICROPHONE Microphone error in the Call Station.
ALARM BUTTON Supervision fault of the alarm button or the key switch.
POWER SUPPLY Power supply out of range.
MASTER
COMBINED FAULT
STATE
The FAULT indicator light on the front panel of the device lights at the occurrence of this type
of error.
Manually setting or resetting an error.
PVA-CSK
The PVA-CSK call station kit is a call station printed circuit board (PCB) for the PAVIRO system. The circuit board
allows an application-specific call station to be installed, such as a fire department call station.
The call station kit is based on the call station, but has been optimized so that it is easy to adapt to different
application areas. In addition to the stem microphone familiar from the PVA-15CST, a dynamic EMERGENCY
microphone such as the DBB 9081 can also be connected. The call station kit equipped with an illuminated LC display
(122 x 32 pixels). The call station has the following features:
– Possible to connect microphone with pre-amplifier and compressor/limiting switch
– Possible to connect five pre-programmed menu/function buttons
– Possible to connect up to 15 function and selection buttons, programmable button assignment
– Possible to connect up to three alarm buttons or key switches
– Possible to connect an external microphone or audio source
– Possible to connect a loudspeaker
– High-resolution LC display
– Comprehensive parameter settings menu on the actual call station
– Microphone and line monitoring
– Error message via LED and buzzer, and error text in the LC display
– Processor control of all functions
– Monitoring of the processor system via watchdog circuit
– Non-volatile FLASH memory for configuration data
The call station is processor-controlled, and equipped with extensive monitoring functions. Line monitoring for the CAN
bus and for audio transmission allows line interruptions and short-circuits to be detected and indicated to the user.
The microphone, PTT button, alarm button and key switch monitoring allows line interruptions and short-circuits to be
detected and reported.
The call stations for the PAVIRO system can be configured quickly and easily using IRIS-Net. A graphical and dialog-
based user interface allows the user to define all button functions, priorities, options, and other properties.
PVA-CSK Device
Start by creating a PVA-CSK device in your IRIS-Net project. Drag a PVA-CSK from the Object Bar’s Devices category or
from the Devices window into the worksheet (see also chapters: Devices and Configurations menu). The following
dialog box appears:
IRIS-Net PAVIRO | en 982
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
