Bosch IRIS-Net User Manual

(empty) This column allows specifying an event (condition) that triggers the
corresponding transmit job code. Clicking the desired line in the Condition
menu opens a dialog field that shows all accessible functions. The table
"Output and Transmit Job Conditions" lists all functions together with their
individual settings.
(empty) Here you can set the different function parameters. For more information,
please refer to the table "Output and Transmit Job Conditions".
(empty) Certain functions allow specifying optional parameter values.
0 ms 0...10027 ms
16.33 ms
Steps
Here, you can program delay or debouncing times. A transmit job code is sent
following a specific event and after the specified time interval has past.
This column allows entering whether a job code is transmitted when the
specified Condition is "true" (no entry) or "false" (click "X" to signal an inverted
state).
Input and Receive Job Function: The following table lists all functions together with their individual settings, which
can be triggered via control input or Receive Job.
Function
Parameter Opt. Value Function executed
Empty - - None
Power off on flip Power Off (Standby) Power On
Power-status change (ON to Stand-by and reverse)
Absolute All DSP
parameters
Corresponding
Parameter
Value
(parameter-
dependent)
Set the specified absolute parameter value for the selected
parameter
Relative All DSP
parameters
Parameter
Value Off- set
(parameter-
dependent)
Changes the actual value of the selected parameter by the specified
offset value
Flip Parameters
with two
statuses
Changes the status of the selected parameter (e.g. bypass On / Off)
Preset U01 - U08, F01 Changes a preset to the specified preset number
Monitor Relay, IN A, IN
B, OUT A, OUT
B
on, off Activates respectively deactivates the selected monitor bus signal
Memo flag Set, Clear,
Toggle Memo
flags 1 - 16
Sets, erases or changes selected memory flags. Up to 16 memory
flags are available and simultaneously accessible.
IRIS-Net REMOTE AMPLIFIER | en 188
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
