Basics of IRIS-NET
IRIS-Net System Requirements
Processor Dual core CPU
OS Windows 7 (32-Bit or 64-Bit), Windows 8 or Windows 8.1
Project Generator or Dx46/DSP 600: The .Net framework (3.5sp1 or higher) is required.
Dante: Windows 7 64-Bit recommended
RAM 2 GB (more is recommended)
Hard Disk 2 GB of free space
Video 1024x768, High Color (16 Bit)
Network Ethernet port and/or 1 USB port per 100 amplifiers
Audio network: Gigabit Ethernet port
Installation
This manual guides the user through the installation process of IRIS-Net using the following operation systems:
Windows 9x, NT, 2000, XP and 7.
1. In Windows click on Start > Run. The Run dialog box appears.
2. Click on the Browse... button. The Browse... dialog box appears.
3. Select the directory in which the IRIS-Net installation file is located.
4. Select "setup.exe" and click on the Open button. The IRIS-Net installation program starts. Follow the instructions
of the installation program.
5. When the installation is finished you can start IRIS-Net from Windows via Start > All Programs > IRIS-Net > IRISNet.
IRIS-Net Directory Structure
This section provides information about IRIS-Net directories and the contained files which, after installing the software
package, are stored on your computer’s hard disk. IRIS-Net’s default installation path is C:\Program Files\IRIS-Net\§
Version §. All subfolders are created in this directory. During installation, defining any other installation path is possible
as well. Subfolders and files will then be created at the new location.
Files installed in the main folder
Amongst others, the main IRIS-Net program folder holds the following files:
Filename Description
IRISnet.exe This is the executable program file. A double click on the file’s icon starts the IRIS-Net
application.
IRIS_readme.pdf ReadMe document offering additional information.
Subdirectories
\Bitmaps.
IRIS-Net IRIS-Net | en 6
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
