Save Saves a project.
About Lists the current application software version.
Online/Offline If current status is offline, Online opens the window Going online.
Please note following hint concerning the Going online dialog:
When being online with a DPM 8016, the IRIS-Net Configuration reads out system parameters which may differ from
the default settings (e.g. running impedance measurement). If these changes are coming from other devices except the
local PC, and the configuration file shall be saved after being online with the system, the user is asked if he wants to
keep the original version or take the current version including the modified parameters.
Controls
PushButton
The IRIS-Net Control of the type "PushButton" is the equivalent of a button. The button has two states: pressed and
unpressed. Left-clicking on the "PushButton" Control activates the "pressed" state. The "unpressed" state is restored
immediately after releasing the mouse button. The button's appearance in both states can be freely configured.
Activating a safety dialog when pressing the button is additionally possible. One or more parameters that are activated
in the "pressed" state can be assigned to a PushButton.
IRIS-Net IRIS-Net | en 83
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
