eq slope 0 / 1 / 2 0 = 0dB/Oct, 1 = 6dB/Oct, 2 = 12dB/Oct
eq frequ 20...20000 [Hz]
eq gain -18...+12 [dB]
eq quality 0.4...40 EQ Quality
xover type 0...17 0 = Off, 1 = 6dB-Butterworth, 2 = 12dB/Q0.5, 3 = 12dB/
Q0.6, 4 = 12dB/Q0.7, 5 = 12dB/Q0.8, 6 = 12dB/Q1.0, 7
= 12dB/
Q1.2, 8 = 12dB/Q1.5, 9 = 12dB/Q2.0, 10 = 12dB-Bessel,
11 = 12dB-Butterworth, 12 = 12dB-Linkwitz, 13 = 18dB-
Bessel, 14 = 18dB-Butterworth, 15 = 24dB-Bessel, 16 =
24dB-Butterworth, 17 = 24dB-Linkwitz
DSP PARAMETER INDEX TABLE
Index
Description Index Description
/PRM/IDX100 input A delay bypass /PRM/IDX160 output A eq2 quality
/PRM/IDX101 input A delay /PRM/IDX161 output A eq3 bypass
/PRM/IDX102 input A eq1 bypass /PRM/IDX162 output A eq3 type
/PRM/IDX103 input A eq1 type /PRM/IDX163 output A eq3 slope
/PRM/IDX104 input A eq1 slope /PRM/IDX164 output A eq3 frequ
/PRM/IDX105 input A eq1 frequ /PRM/IDX165 output A eq3 gain
/PRM/IDX106 input A eq1 gain /PRM/IDX166 output A eq3 quality
/PRM/IDX107 input A eq1 quality /PRM/IDX167 output A eq4 bypass
/PRM/IDX108 input A eq2 bypass /PRM/IDX168 output A eq4 type
/PRM/IDX109 input A eq2 type /PRM/IDX169 output A eq4 slope
/PRM/IDX10A input A eq2 slope /PRM/IDX16A output A eq4 frequ
/PRM/IDX10B input A eq2 frequ /PRM/IDX16B output A eq4 gain
/PRM/IDX10C input A eq2 gain /PRM/IDX16C output A eq4 quality
/PRM/IDX10D input A eq2 quality /PRM/IDX16D output A eq5 bypass
/PRM/IDX10E input A eq3 bypass /PRM/IDX16E output A eq5 type
/PRM/IDX10F input A eq3 type /PRM/IDX16F output A eq5 slope
/PRM/IDX110 input A eq3 slope /PRM/IDX170 output A eq5 frequency
/PRM/IDX111 input A eq3 frequ /PRM/IDX171 output A eq5 gain
/PRM/IDX112 input A eq3 gain /PRM/IDX172 output A eq5 quality
/PRM/IDX113 input A eq3 quality /PRM/IDX173 output B level
/PRM/IDX114 input A eq4 bypass /PRM/IDX174 output B trim level
/PRM/IDX115 input A eq4 type /PRM/IDX175 output B delay bypass
IRIS-Net REMOTE AMPLIFIER | en 163
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
