DSP The DSP page provides an overview plus access to all DSP functions (Filter, Delay, X-Over, Limiters)
of the amplifier.
Speaker This page allows loading and displaying speaker data.
Load This page provides access to several settings for impedance/load monitoring and impedance
testing.
Supervision &
Test
This page allows configuring monitoring and surveillance functions and setting the test tone
generator.
For more detailed information please refer to the corresponding chapters of the Remote Amplifier.
RCM26DSPUI
The RCM26DSPUI Dialog is used for linearization and secure operation of a single loudspeaker. An FIR-filter, equalizer,
a crossover and limiters are presented in separate window. This allows comfortably adjusting all the specific settings
that are necessary for the operation of a single loudspeaker chassis (or individual way of a loudspeaker system) in a
separate window. All settings/parameters can be saved in configuration files (Speaker Settings). Pre-defined
configuration files (Speaker Settings) are available for loudspeakers from Electro-Voice and DYNACORD.
The RCM26DSPUI Dialog can be accessed via a Group or a PushButton. In the properties of the respective element you
have to select the setting "RCM26DSPUI" in the dropdown field "Dialog opened by Double Click". The two tabs "DSP"
and "Speaker" can be found in the main window of the RCM26DSPUI Dialog. The DSP tab provides access to the flow
diagram to make all necessary settings.
IRIS-Net
IRIS-Net | en 93
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
