Load This page provides access to several settings for impedance/load monitoring and impedance
testing.
Supervision &
Test
This page allows configuring monitoring and surveillance functions and setting the test tone
generator.
Clicking on the „SET“ soft key in the Amplifier Control Panel opens the Setup & Control window.
Config & Info
The Config & Info window provides information and basic settings for the selected amplifier. Additionally, editing labels
is possible in this window.
To select the page click on the Configuration & Information tab in the Setup & Control Window.
Amplifier Info
Element
Description
AMPLIFIER
MODEL
Shows the amplifier type
AMPLIFIER
FIRMWARE
Shows the amplifier‘s software version number (operating system, firmware)
RCM-26
FIRMWARE
Shows the remote control module‘s software version number (operating system, firmware)
OPERATING
MODE
Shows the amplifier’s operating mode. The power amplifier can be operated in NORMAL or
BRIDGED mode.
AMP ROUTING Shows how the amplifier's audio inputs handle the input signals. Possible amp routings are DUAL
and PARALLEL.
GROUND LIFT Shows the setting of the amplifier's GROUND LIFT switch. Possible settings are GROUNDED and
UNGROUNDED.
UPTIME Shows the uptime of the amplifier (standby not included) since the last reset of the Event Log.
For further details about the amplifier’s Event Log please refer to the owner's manual.
MAINS VOLTAGE Shows the mains voltage and the mains current consumption.
IRIS-Net REMOTE AMPLIFIER | en 182
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
