OWNER_PW A password for owner presets protection is defined
OWNER_ID The owner is identified by password, manipulation of owner presets is possible (can be cleared by
command)
AES_OK Die AES/EBU Schnittstelle ist in Ordnung
AESINPUT Es wird das Audio-Signal der AES/EBU Schnittstelle statt dem Audio-Signal am analogen Eingang
verwendet
CANADDR Die CAN-Adresse wurde per Software gewählt, die Adress-Einstellung an der Blende des RCM-26 wird
ignoriert
Input Channel State Flags
Flag
Description
PILOT The 19 kHz pilot tone is not detected above threshold
Output Channel State Flags
Flag
Description
PSOVL The SMPS reports overload
HFDET The power amplifier reports excessive HF level
SHORTED A low impedance load or short-circuit is detected
THERMPROT The amplifier's thermal protection is active (protect-mode)
PROTECT In general: protect-mode active
AMPFAIL A amplifier failure was detected (output is muted via relay off)
MUTE The output is muted via relay off
GNDFLT A ground fault has occurred
GAINRED The amplifier's gain reduction is active (protect-mode)
DISHI Rail voltage: step high disabled
DISMID Rail voltage: step mid disabled
Z_VALID The calculated load value (U/I) is actually valid
Z_MIN The load is below minimum, shorted
Z_MAX The load is above maximum, open
PILOT The 19 kHz pilot tone is not detected above threshold
MEAS The sweep measurement is active
THRM_HDRM The thermal headroom is below minimum
IRIS-Net REMOTE AMPLIFIER | en 232
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
