Control Inputs - GPI Functions
Every control input can be programmed with individual functions for switching on (/CONTROL/INx/ON/...) and
switching off (/CONTROL/INx/OFF/...). When the state of a control input changes, the programmed function is
executed after the previously set delay or debounce times are expired (up to 10 sec.). Available functions are explained
in the following table.
Job Codes - Receive Functions
Job codes are distributed throughout the CAN network via broadcast commands. Each job code has a freely definable
number (ID). Received job codes can trigger the same functions as local GPI control inputs. Receiving a job code with
the defined number (ID) triggers the function with its specified parameter values. Available functions for /JOB/RXx/
FNCT/... and corresponding parameters /JOB/RXx/PRM/... are identical with local GPI functions, as outlined in the
table.
Function Parameter Range Description
NOTHING No function
POWER Controls Power On / Stand-by
../PRM/SWITCH ON Switches the amp's power to ON
OFF Switches the amp in Stand-by mode
FLIP Toggles between ON and Stand-by and vice versa
ABS Sets the selected DSP parameter to an absolute
value
../PRM/TYPE IN / OUT IN selects input channel, OUT selects output
channel
.../PRM/CHAN A / B / A,B Selects channel A, or channel B, or channel A
and B
../PRM/IDX 00...FF Selects the DSP parameter via index number
../PRM/VALUE New absolute parameter value
REL Changes the selected DSP parameter in relation
to the actual value
../PRM/TYPE IN / OUT IN selects input channel, OUT selects output
channel
.../PRM/CHAN A / B / A,B Selects channel A, or channel B, or channel A
and B
../PRM/IDX 00...FF Selects the DSP parameter via index number
../PRM/VALUE Relative change of the parameter
TOGGLE Toggles a DSP parameter between 0 and 1 (this
only makes sense for flag parameters, e.g. MUTE,
BYPASS, etc.)
.../PRM/TYPE IN / OUT IN selects input channel, OUT selects output
channel
IRIS-Net REMOTE AMPLIFIER | en 233
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
