/PRM/IDX14E output A limiter
bypass
/PRM/IDX14F output A limiter
threshold
/PRM/IDX150 output A limiter
release
/PRM/IDX151 output A xover
hipass type
/PRM/IDX152 output A xover
hipass frequ
/PRM/IDX153 output A xover
lopass type
/PRM/IDX154 output A xover
lopass frequ
/PRM/IDX155 output A eq1 bypass
/PRM/IDX156 output A eq1 type
/PRM/IDX157 output A eq1 slope
/PRM/IDX158 output A eq1 frequ
/PRM/IDX159 output A eq1 gain
/PRM/IDX15A output A eq1 quality
/PRM/IDX15B output A eq2 bypass
/PRM/IDX15C output A eq2 type
/PRM/IDX15D output A eq2 slope
/PRM/IDX15E output A eq2 frequ
/PRM/IDX15F output A eq2 gain
Control Inputs - GPI Functions
Every control input can be programmed with individual functions for switching on (/CONTROL/INx/ON/...) and
switching off (/CONTROL/INx/OFF/...). When the state of a control input changes, the programmed function is
executed after the previously set delay or debounce times are expired (up to 10 sec.). Available functions are explained
in the following table.
Job Codes - Receive Functions
Job codes are distributed throughout the CAN network via broadcast commands. Each job code has a freely definable
number (ID). Received job codes can trigger the same functions as local GPI control inputs. Receiving a job code with
the defined number (ID) triggers the function with its specified parameter values. Available functions for /JOB/RXx/
FNCT/... and corresponding parameters /JOB/RXx/PRM/... are identical with local GPI functions, as outlined in the
table.
IRIS-Net REMOTE AMPLIFIER | en 166
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
