Bosch IRIS-Net User Manual

Ethernet On-line Dialog
Element Description
Name of the device. The checkbox in front of the name of a device
allows selecting the unit as a connecting device. A connection will
be established only with selected devices.
The IP address of the device in IRIS-Net. Connection fails, if the IP
address specified in IRIS-Net differs from the actual IP address of
the unit.
Indicates the current connection status of the device.
Read All from Selected Devices Reads all settings of connected device and transfers them to IRIS-
Net.
Load Amplifier Presets Additionally reads the presets of all connected Remote Amplifiers.
Send All to Selected Devices Writes the DSP configuration and all settings into memory of
connected devices.
Save Amplifier Presets Additionally writes the presets of all Remote Amplifiers.
RCM-24: Save Current DSP Settings to Reserved
User Memory U01
Additionally writes the current DSP settings into the User Memory
U01 of all power amplifiers with RCM-24 Remote Control Module
installed.
Connect only (data would not be synchronized) No synchronization; i.e. data (DSP configuration, settings, presets)
is not transferred to the devices nor read from the devices.
IRIS-Net
IRIS-Net | en 14
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
