Element
Description
Select Control Object Switching between Controls for editing is possible if a variety of Controls of the type
"PushButton" are used in a project.
The currently selected PushButton is deleted in the IRIS-Net project.
Caption Text label of the PushButton. The entered text is always displayed centered.
Confirm Text If it is intended that a safety dialog appears when left-clicking on the button, this field lets
the user enter an explanatory text to be displayed in that safety dialog. If no text is being
entered, the safety dialog does not appear.
Textcolor when Button is
pressed
Color of the button label when in the "pressed" state. The button opens the Color dialog
which allows selecting between predefined and user-definable colors.
Textcolor when Button is
unpressed
FColor of the button label when in the "unpressed" state. The button opens the Color
dialog which allows selecting between predefined and user-definable colors.
Font Displays the currently selected typeface for button labeling. The button opens the
"Typeface" dialog which allows selecting font type, font style/weight, and font size.
Bitmap Displays the filename of the bitmap graphic file that is currently used to represent the
pushbutton. The button opens the "Bit- maps" dialog which allows selecting the desired
bitmap file to represent the pushbutton.
Dialog opened by Click Allows selecting a dialog that opens when pressing the PushButton.
Lists the functions (WHAT-part of the parameter) that are active when the PushButton is
in the "pressed" state. Removing items is possible by opening the contextual menu of the
function that is to be deleted and selecting the entry "Delete Entry".
IRIS-Net IRIS-Net | en 84
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
