Bosch IRIS-Net User Manual

Function Parameter Range Description
NOTHING No function
POWER Interpretation results in "true", when the power amp is powered on
(even during power-on delay) and "false", when the amp's power is off.
ABS Interpretation results in "true", when the DSP parameter value is higher
or equals the reference value.
../PRM/IDX 100...1A5 Selects the DSP parameter via index number
../PRM/
VALUE
Reference value
TEMP Interpretation results in "true", when the measured amplifier
temperature is higher or equals the reference value.
../PRM/
CELSIUS
-20...150 [°C] Temperature reference value
VU Interpretation results in "true", when at least one of the selected values
is higher or equals the programmed reference value.
../PRM/SEL IN_A, OUT_A,
ALIM_A,
DLIM_A,
COMP_A, IN_B.
OUT_B, ALIM_B,
DLIM_B,
COMP_B
Any combination of the values listed is possible. ALIM = Amplifier
Limiter
DLIM = DSP Limiter COMP = DSP Compresser
../PRM/DB [dB] VU reference value
CTL_IN Interpretation results in "true", when the selected control input is
activated.
../PRM/IDX 1, 2 Selects a control input
ERRFLAG Interpretation results in "true", when one of the selected flags is set.
Any combination of the flags listed is possible.
../PRM/MASK POWER set, when the power is OFF
STANDBY set, when the amplifier is in Stand-by mode
PROTECT set, when the amp's Protect mode is activated
OVT set, when the amp's thermal limit is exceeded
GNDFLT_A,
GNDFLT_B
set, when ground fault has been detected
ZMIN_A,
ZMIN_B,
ZMAX_A,
ZMAX_B
set, when the measured output load is out of limit value range
IRIS-Net REMOTE AMPLIFIER | en 169
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
