Element Description
Online/Offline The Online / Offline indicator signals whether the selected receiver is included in the network or
off-line. The red OFFLINE indicator signals that the corresponding receiver is off-line and that
therefore no communication is possible. The green ONLINE indicator shows that the corresponding
receiver is on-line and that sending and receiving data is possible. When on-line, any parameter
changes are immediately trans- mitted and active.
Left Rcvr / Right
Rcvr
Select the left or the right receiver.
HINT: The receiver selection option is disabled in a REVS receiver.
Tone Select „On“ to activate the dropout tone. When the receiver increments the dropout counter, it will
also send a 1 kHz audio tone out the out- put so you can hear where on the stage the drop occurs.
Select „Off“ to turn off the tone.
Audio This Peak Hold Audio Meter allows you to set the transmitter gain as high as possible for the
application which maximizes the signal to noise ratio. Sing, yell or play the guitar at the loudest
desired volume and adjust the gain so the meter peaks between 50 and 100.
RF Signal This Low Hold RF Meter will tell you if you have adequate coverage in the performance area. If the
RF level drops below 10 on the meter during a walk of the desired area, reposition the antennas, or
change the channel and retest.
Count Counter indicates the number of times the range was exceeded or some interference problems that
was dealt with.
Start Click Start to start the Sound check operation
Stop Click Stop to stop the Sound check operation
Current Group Current group indicates the group currently assigned to the receiver.
Copy Group Copy group option lists the available user groups in the receiver.
Copy Selecting a group and clicking this button copies a group in to the selected user group.
Clear Group Clear group option is enabled only if the current group is a user group. Clear group option lists the
available user groups in the receiver.
Clear Selecting a group and clicking this button clears the selected user group.
Squelch The squelch setting can be used to maximize range or immunity to noise.
Audio Out Audio Out lists option for modifying the audio output to either „Mic“ or „Line“
XLR Level Allows adjusting the signal level at the XLR output.
HINT: XLR Level is editable only if the Audio Out is selected as ‘Line’.
Hi Z Level Allows adjusting the signal level at the Hi Z output.
IRIS-Net REV WIRELESS MICROPHONE SYSTEM | en 314
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
