AUDIO MUTE Audio transmission has been muted, because correct transmission
cannot be guaranteed.
SYNC Synchronizing the DSP system to CobraNet is not possible.
WATCHDOG The CM-1 is being reset because of a hardware or software failure.
INTERFACE An error has been detected in the communication with the CM-1
interface.
FATAL ERROR A fatal error has been detected within the CM-1.
ERROR DISPLAY Displays the corresponding error code for detected faults. 0 = no fault.
If an error code is being displayed, this button allows recalling
information about the detected error.
BUNDLE Number of the received bundle.
RECEPTION Indicates whether or not a bundle is currently received.
CHn Displays the corresponding Resolutions of all channels of the received
bundle.
LOAD A bundle’s utilization ratio in percent. The load depends on the number
and resolution of the channels transmitted in a bundle.
BUNDLE Number of the transmitted bundle.
RECEPTION Indicates whether or not another unit receives the transmitted bundle.
CHANNELS Number of channels transmitted in a bundle.
CHn Displays the corresponding Resolutions of all channels of the
transmitted bundle.
LOAD A bundle’s utilization ratio in percent. The load depends on the number
and resolution of the channels transmitted in a bundle.
DM-1
This window provides detailed information about a DM-1 Dante Interface module installed in the N8000. The DSP
blocks Dante Inputs and Dante Outputs (see DANTE INPUTS, page 386) provide the possibility to select and configure
Dante channels.
HINT: The Dante Configuration dialog (menu Tools > Dante Configuration) provides the possibility to configure the
Dante network.
IRIS-Net DIGITAL MATRIX | en 325
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
