EQ - Graphic n Band Graphic
EQ
1 1 Graphic Equalizer in Mono/Stereo with 10, 15 or 31 bands.
Two parametric EQs are provided as well.
n Band Stereo
Graphic EQ
2 2
EQ -
Parametric
n Band PEQ 1 1 Parametric Equalizer in Mono/Stereo with 1 to 32 bands.
Freely selectable filter types (PEQ, Low/High-Shelving,
Low/High/All Pass) with the following parameters: gain,
frequency, quality/bandwidth or slope for each band.
n Band Stereo
PEQ
2 2
Filter FIR Filter 1 1 Finite Impulse Response blocks with order 256, 512, 768,
1024, 1280, 1536 or 1792. Possible filter types are Low
Pass, High Pass or Band Pass.
Low Pass Mono 1 1 Low Pass blocks in Mono/Stereo with the following
parameters: frequency, slope and quality.
Low Pass
Stereo
2 2
High Pass Mono 1 1 High Pass blocks in Mono/Stereo with the following
parameters: frequency, slope and quality.
High Pass
Stereo
2 2
Band Pass
Mono
1 1 Band Pass blocks in Mono/Stereo with the following
parameters: frequency and quality/bandwidth.
Band Pass
Stereo
2 2
Low Shelf
Mono
1 1 Low Shelf blocks in Mono/Stereo with the following
parameters: frequency, slope and gain.
Low Shelf
Stereo
2 2
High Shelf
Mono
1 1 High Shelf blocks in Mono/Stereo with the following
parameters: frequency, slope and gain.
High Shelf
Stereo
2 2
Notch Mono 1 1 Notch blocks in Mono/Stereo with the following
parameters: frequency and quality/bandwidth.
Notch Stereo 2 2
Allpass Mono 1 1 Allpass blocks in Mono/Stereo with the following
parameters: frequency and order.
Allpass Stereo 2 2
Tone Control
Mono
1 1 Tone Control blocks in Mono/Stereo with gain controls for
Bass/Mid/Treble.
Tone Control
Stereo
2 2
FIR
Controllers
n-Way Mono
FIR Controller
1 1 FIR Controller blocks in Mono/Stereo with 1 to 5 ways.
Each way has a 6- Band PEQ, a crossover with polarity,
alignment delay, FIR filter, level control and a compressor/
2
IRIS-Net DIGITAL MATRIX | en 365
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
