Loudspeaker
Controllers
n-Way LS
Controller
1 1 Loudspeaker Controller blocks in Mono/Stereo with 1 to 5
ways.
Each way has a 6-Band PEQ, a crossover with polarity,
alignment delay, level control and a compressor/limiter.
Importing factory-made Speaker Settings for each
Loudspeaker Controller way is possible. Exporting custom
parameter sets as Speaker Settings is possible as well.
2
3
4
5
n-Way Stereo
LS Controller
2 2
4
6
8
10
Matrix/Router I x O Matrix
Mixer
2...32 2...32 The Matrix Mixers have between 2 and 32 inputs and
between 2 and 32 out- puts.
Each input or output and each node of the matrix have
individual level controls. An arbitrary amount of existing
inputs can be mixed down to a single or several outputs.
I x O Priority
Matrix
2...32 2...32 The Priority Matrix has between 2 and 32 inputs and
between 2 and 32 out- puts.
Setting a priority for each input is possible. All outputs and
all nodes of the matrix have individual level controls.
I x O Matrix
Router
2...32 2...32 The Matrix Router has between 2 and 32 inputs and
between 2 and 32 out- puts.
All inputs and outputs have individual level controls. Each
input can be assigned to a single or several outputs.
However, only one input can be active per output.
Router 1...32 1...32 Router blocks with between 1 and 32 inputs and between
1 and 32 outputs. Each output can be fed by a single input
source signal only. However, assigning an input to several
outputs is possible.
Mixer Mono Mixer 2..32 1 The Mono or Stereo Mixers have between 2 and 32 inputs
and 1or 2 outputs. Each input has a fader, signal/clipping
LEDs, Mute, Solo and Invert buttons while output channels
have a fader, signal/clipping LEDs and a Mute button.
Stereo Mixer 2...32 2
Automixer 2 3 The Auto Mixers have 2, 4, 6, 8, 10, 12, 16 or 24 inputs/
outputs and 1 additional auto mixed output.
Each input has fader, meter, signal/clipping LEDs, Mute,
Solo, Invert, Prio buttons and Auto checkbox while the
auto mixed output has a fader, meter, Mute, Invert and
Freeze Gain button.
HINT: For using the automixer block with 16 or 24 inputs
a DSP-2DSP Extension Module is required.
4 5
6 7
8 9
10 11
12 13
16 17
IRIS-Net DIGITAL MATRIX | en 367
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
