DANTE INPUTS
The Dante Inputs DSP block is part of the DM-1 Dante Interface module. The dialog provides 8 input
channels from a Dante network.
Element
Description
LINK This LED indicates the input channel’s current reception status. Whenever
data is being received, the LED lights green. Whenever there is no data
stream received via Dante, the LED lights red.
DEVICE The Drop-Down field allows selecting the name or description of the
device the channel is received from.
CHANNEL The Drop-Down field allows selecting the name or description of the
received channel.
The ”SIG” LED lights whenever a signal is being received on the channel.
The "0dB" LED light additionally, when the signal’s level is close to
clipping.
The MUTE button allows muting the corresponding channel.
Text field for assigning the Dante Channel Name to the corresponding
channel. The name is also used in the Dante Controller.
CAUTION: Using * (asterisk) or = (equal) within a name is not
permissible.
IRIS-Net
DIGITAL MATRIX | en 386
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
