Element Description
The "SIG" LED lights if a channel transmits a signal. In addition, the "0dB" LED lights whenever
the level of the signal reaches the 0dB mark, signaling that there is a chance of driving the signal
into distortion.
The MUTE button allows muting the corresponding channel.
Text field for assigning the OMNEO or Dante Transmit Channel Name to the corresponding
channel. The name is also used in the Dante Controller.
CAUTION: The use of * (asterisk) and = (equal) in names is not permissible.
DELAY
The Delay DSP blocks allow the utilization of delay lines. This, for example, allows sending differently
delayed audio signals to PA towers at open-air concerts to compensate for differences in distance among individual
loudspeaker arrays. Alignment delay settings to compensate for individual transducers in a loudspeaker cabinet being
mounted on different radiation planes is also possible.
Delay blocks in monaural quality (1 input and 1 output) and stereo quality (2 inputs and 2 outputs) are available. Both
types allow for delay times of 10, 100, 500 or maximally 2000 ms.
IRIS-Net
DIGITAL MATRIX | en 389
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
