DIGITAL INPUTS
The Digital Inputs DSP block provides access to the eight digital inputs of an DI-1 Digital Input card.
Establishing independent settings for each input channel is possible. A fader with ramping function as well as Mute and
Invert buttons serve as controls. Each input channel has its individual level meter. Adjacent channels can be linked
together using the LINK button. This allows simultaneous setting of several input channels, e.g. for stereo signals.
Element
Default Range Description
The receivers are consecutively numbered from
RECEIVER 1 to RECEIVER 4, offering two input channels,
each.
Switching the receiver’s signal type. The DI-1 card’s
electrical inputs are capable of processing AES/EBU or
S/P DIF compatible audio signals. Switching between
the two formats has to be performed manually, using the
appropriate labeled buttons.
When using the optical input, select OPTICAL as the
signal type.
IRIS-Net DIGITAL MATRIX | en 391
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
