Element Default Range Description
0.001 s 0.001...20 s A ramping time can be set for a channel’s fader. When
changing the signal level via Fader or Fader Display,
within the previously specified period of time, the
new signal level is set by means of the ramping
function.
The checkbox allows activating the channel’s pilot
tone generator.
HINT: Gen. Used can only be configured OFFLINE.
-35.0
dBu
-60...0 dBu This field allows setting the level of the pilot tone
signal.
HINT: Level (dBu) can only be configured OFFLINE.
19000
Hz
20...20000 Hz This field allows setting the frequency of the pilot
tone signal. The set frequency applies to all outputs,
for which the pilot tone signal has been activated.
HINT: Freq (Hz) can only be configured OFFLINE.
DUCKER
The Ducker DSP block reduces the level of a signal at the LINE input whenever a signal is present at the
MIC input. If there is no MIC signal present the LINE signal automatically returns to its preset level.
Element Default Range Description
This indicator signals in dB by how much
the ducker reduces the signal level. A red
bar that increases from the right to the
left indicates the degree of gain reduction.
IRIS-Net DIGITAL MATRIX | en 396
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
