0 dB -18...6 dB Fader for setting the output level.
The fader display shows the numerical value of the
current fader setting and also provides the possibility for
entering a desired value.
GRAPHIC EQUALIZER
IRIS-Net provides 10, 15 and 31 band graphic equalizers in monaural and stereo quality.
Element
Default Range Description
Switch to select magnitude or phase indication
Switch to scale the amplification axis to 25 dB (± 12.5 dB) or
50 dB (± 25 dB)
Switch to select whether white points are visible during
frequency response indication, or not.
Switch to determine whether bandwidth BW or quality Q are
selected when setting the current filter.
IRIS-Net DIGITAL MATRIX | en 417
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
