RMS-COMPRESSOR (RCM-24)
The characteristics of the Compressor (RCM-24) offered by IRIS-Net is identical to the compressors used
in Precision Series power amps.
Element Default Range Description
This bar meter indicates gain reduction in dB, i.e. by
how much the Compressor reduces the signal level. A
red bar that increases from right to left indicates the
degree of gain reduction.
0.0 dBu
or
0.775 V
-9.0...+21.0
dBu or
0.275...8.69
6 V
THRESHOLD defines the signal level at which the
Compressor sets in. Entering the desired value is
possible in dBu as well as in V. The entered value is
automatically converted in both directions.
1.0:1 1.0:1, 1.4:1,
2.0:1,
4.0:1, 8.0:1
RATIO defines the compression rate, i.e. the degree of
compression above the threshold level. For example, a
rate of 4.0 : 1 represents a signal reduction by factor
4.
5 ms 5...150 ms ATTACK defines the velocity, at which the compressor
sets in. A short attack rate means that even short
signal peaks are efficiently compressed. Longer attack
rate leave signal peaks untouched.
