0 dB -12...+12
dB
MID changes (amplifies or attenuates) the gain of a Mid-EQs
(Peak-Dip-Filter). The filter’s center frequency is fixed to 1 kHz.
The desired amplification or attenuation can be set by directly
entering the desired value or by using the rotary control.
0 dB -12...+12
dB
TREBLE changes (amplifies or attenuates) the gain of a Treble
filter (High-Shelving-Filter). The filter’s cut-off frequency is fixed
to 1,5 kHz. The desired amplification or attenuation can be set
by directly entering the desired value or by using the rotary
control.
TONE GENERATOR
Operating the DSP block Tone Generator is possible in two different ways.
Sine mode generates a sine signal with a constant frequency. Sweep mode
generates a one-time or periodical sine sweep over a specific frequency
range.
Element
Default Range Description
The SINE button puts the tone generator in constant sine signal
mode.
