Audio Interface Faults
Error Description
Boot Booting the DSP system failed, Audio Processing is not possible. Please refer to the
correspondent Log File entries
Delay RAM Delay RAM fault. Audio Processing using the concerned RAM areas is not possible. Please
refer to the correspondent Log File entries
Watchdog One processor of the DSP system signals the occurrence of an error. Please refer to the
correspondent Log File entries
Pilot Tone Detection At least one of the pilot tone detections in the N8000’s DSP configuration is not able to
detect the pilot signal
R/W Base Config Error while reading or writing the DSP Base Configuration
R/W Config Error while reading or writing the DSP Configuration
Invalid Config Unable to process invalid DSP Configuration
R/W Preset Error while reading or writing a DSP Preset
Invalid Preset Unable to process an invalid DSP Preset
Incompatible Preset Selected DSP Preset and current DSP Configuration are not compatible
OS Memory An error occurred when the operating system of the N8000 tried to access the memory
HW Config Slot 1 The DSP configuration of Audio Slot 1 does not represent the actual hardware configuration
HW Config Slot 2 The DSP configuration of Audio Slot 2 does not represent the actual hardware configuration
HW Config Slot 3 The DSP configuration of Audio Slot 3 does not represent the actual hardware configuration
HW Config Slot 4 The DSP configuration of Audio Slot 4 does not represent the actual hardware configuration
HW Config Ext. Slot The DSP configuration requires an extension board connected to the extensions port, but
there is no board connected
HW Config Cobranet The DSP configuration requires a CobraNet board installed in the network module slot, but
there is no board installed
Cobranet Interface An error occurred during communication with the CM-1 interface
IRIS-Net DIGITAL MATRIX | en 498
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
