The DSP 244 offers 7 pre-defined configurations. A configuration is a basic setting that
includes the routing of inputs and out- puts, the function of the outputs (Sub, Lo, Mid, Hi,
Fullrange), as well as the kind and amount of parameters. If you do not want to use one of
the pre-defined configurations, you have also the possibility to operate the DSP 244 in
Full Edit mode. This mode offers access to all parameters and basically any input/output
routing can be programmed. Additionally, the output assignment (output function - Sub,
Lo, Mid, Hi, Fullrange) is also freely definable.
If the sound system processor is operated in Full Edit Mode, clicking the button LED
Config opens the LED Configuration dialog.
Recall a Presets
Element
Description
Clicking the button RECALL... opens the Recall Preset dialog, where you can select and recall a
Preset.
IRIS-Net
DIGITAL SOUND PROCESSOR | en 584
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
